Pilot Exterior (PEX)

  • color changing
  • low profile cove/grazer
Cove/Graze Lighting for Exterior Rated IP67 for exterior use


  • Pilot Exterior (PEX) Specification Sheet Pilot Exterior (PEX) Specification Sheet Specification Sheet
  • IES Files IES Files
  • Revit Files Revit Files
  • Pilot Exterior (PEX) Installation Instructions Pilot Exterior (PEX) Installation Instructions Installation Instructions
  • Pilot Exterior (PEX) Wiring Instructions Pilot Exterior (PEX) Wiring Instructions Wiring Instructions
  • Pilot Exterior (PEX) Product Comparison Guide Pilot Exterior (PEX) Product Comparison Guide Product Comparison Guide
  • Pilot Exterior (PEX) Warranty Pilot Exterior (PEX) Warranty Warranty
Share this product page
Facebook Twitter LinkedIn Email Pinterest


Pilot Exterior (PEX)

A low-profile cove and wall grazer for exterior applications.
Featuring Patented Quad Chip Technology. Powered by Nitro Color.

Product Family: Cove (Pilot)

  • Light Source:

    6 W/Ft, 12 W/Ft

  • CCT:

    RGB30K, RGB40K, RGBA,

  • AWH (Kelvin Tunable 22K-65K)

  • Optics:

    10°X10°, 10°X30°, 10°X60°, 15°X15°, 15°X30°, 15°X60°, 20°X20°, 20°X60°, 30°X30°, 30°X60°, 40°X40°, 40°X60°, 60°X60°, 100°X100°, Asymmetric

  • Voltage:

    120V or 277V

  • Power:

    Integrated Power Supply

  • Control:

    DMX / RDM

  • Dimensions:

    2.5" x1.75" x 12" or 48"

  • Weight:

    12": 1.65 Lbs, 48": 6 Lbs

  • Housing:

    Extruded Aluminum Housing

  • Lens:

    Tempered Glass Lens

  • Finish:

    Metallic Gray

  • Warranty:

    5-Year Limited

  • Operating Temp:

    -40° C To 50° C

  • Lumen Maintenance:

    75,000 Hours

  • Certification:

    ETL/cETL For Wet Location, IP67, 3G
