Pilot Exterior (PEX)

  • white light
  • low profile cove and grazer
Cove/Graze Lighting for Exterior Rated IP67 for exterior use


  • Pilot Exterior (PEX) Specification Sheet Pilot Exterior (PEX) Specification Sheet Specification Sheet
  • IES Files IES Files
  • Revit Files Revit Files
  • Pilot Exterior (PEX) Installation Instructions Pilot Exterior (PEX) Installation Instructions Installation Instructions
  • Pilot Exterior (PEX) Wiring Instructions Pilot Exterior (PEX) Wiring Instructions Wiring Instructions
  • Pilot Exterior (PEX) Product Comparison Guide Pilot Exterior (PEX) Product Comparison Guide Product Comparison Guide
  • Pilot Exterior (PEX) Warranty Pilot Exterior (PEX) Warranty Warranty
Share this product page
Facebook Twitter LinkedIn Email Pinterest

White Light & Static Colors

Pilot Exterior (PEX)

A low-profile cove and wall grazer for exterior applications.

Product Family: Cove (Pilot)

  • Light Source:

    4W/Ft, 7W/Ft, 10W/Ft

  • CCT's:

    2700K, 3000K, 3500K, 4000K

  • Static colors:

    Red, Blue, Green, Amber

  • Optics:

    10°X10°, 10°X30°, 10°X60°, 15°X15°, 15°X30°, 15°X60°, 30°X30°, 30°X60°, 60°X60°, 100°X100°, Asymmetric

  • Performance:

    Up To 48038 Peak Candela

  • Voltage:

    120V or 277V

  • Power:

    Integrated Power Supply

  • Dimming:

    Flicker Free Dimmable To 1%. 0-10V, (Sink), DMX Dimming

  • Lengths:

    12" And 48"

  • Weight:

    12.0": 1.65 Lbs, 48.0": 6 Lbs

  • Housing:

    Extruded Aluminum

  • Lens:

    Tempered Glass

  • Finish:

    High Durability Powder Coating

  • Operating Temp:

    -40° C To 50° C

  • Warranty:

    5-Year Limited

  • Lumen Maintenance:

    75,000 Hours

  • Certification:

    ETL/cETL For Wet Location, IP67, 3G
