Prospot Ingrade Large

  • white light
  • in-ground performance projector
In-Ground Performance Linear Interior Rated IP68 for exterior use
Prospot Ingrade Large In-Ground Performance Linear Prospot Ingrade Large In-Ground Performance Linear
Prospot Ingrade Large

A high-performance in-grade projector.

Product Family: Projector (Prospot)

Certifications & Compliance: Turtle-Friendly
Share this product page
Facebook Twitter LinkedIn Email Pinterest

  • Output:

    Standard Output (30W)

  • Distribution:

    6°X6°, 10°X10°, 20°X20°, 30°X30°, 50°X50°, Wall Wash, HSL (10°X53°)

  • CCT:

    2700K, 3000K, 3500K, 4000K

  • CRI:

    80+

  • Voltage:

    120VAC, 277VAC

  • Power:

    Integrated Power Supply

  • Control:

    0-10V, DMX Dimming

  • Dimensions:

    Ø 8.46"

  • Housing:

    Die-cast Aluminum

  • Mounting:

    Ingrade

  • Lens:

    Clear Tempered Glass

  • Trim Finish:

    Brushed Stainless Steel

  • Warranty:

    5-Year Limited

  • Operating Temp:

    -25° C to 50° C

  • Lumen Maintenance:

    80,000 Hrs

  • Certification:

    IP68, IK10

  • Note:

    39.37" Deep for up to 36 hours. Not suitable for permanent submersion

  • Drive Over Rating:

    Walk/drive over compliant up to 6000 lbs in concrete pour
Product Image

    Prospot Ingrade Large Downloads

    Specification Sheets

    Prospot Ingrade Large White Light Specification Sheet |
    Preview Preview Specification Sheet | Download Download Specification Sheet

    Warranty

    Standard Warranty |
    Preview Preview Warranty | Download Download Warranty
