Smart Blade (PRDI)

  • white light
  • illuminated linear blades
  • in production
Illuminated Linear Blades Interior
Slide 7

Illuminated Linear Blades

previous arrow
next arrow
Smart Blade (PRDI) Illuminated Linear Blades
Share this product page
Facebook Twitter LinkedIn Email Pinterest

  • Light Source:

    8 W/FT

  • CCT:

    2700K, 3000K, 3500K, 4000K

  • Color Tolerance:

    ± 200

  • Performance:

    Up To 82.0 LM/W

  • Voltage:

    120VAC or 277VAC (240V Unavailable)

  • Power Supply:

    Integrated Power Supply

  • Dimming:

    0-10V

  • Dimensions:

    2.10" X 1.41" X 12.00" - 2.10" X 1.41" X 48.00"

  • Weight:

    DETERMINED BY LENGTH OF FIXTURE

  • Housing:

    Extruded Aluminum Housing

  • Lens:

    Transparent Cast Acrylic, Laser Etched

  • Finish:

    High Durability Powder Coating

  • Warranty:

    5-Year Limited

  • Operating Temperature:

    -20° C To 40° C

  • Lumen Maintenance:

    75,000 Hours L70

  • Certification:

    UL 48 Standards

    Smart Blade (PRDI) Downloads

    Specification Sheets

    Smart Blade White Light Specification Sheet |
    Preview Preview Specification Sheet | Download Download Specification Sheet

    Installation Instructions

    Smart Blade Installation Instructions |
    Preview Preview Installation Instructions | Download Download Installation Instructions
    Smart Blade Color Changing Wiring |
    Preview Preview Installation Instructions | Download Download Installation Instructions

    Wiring Instructions

    Smart Blade White Light Wiring |
    Preview Preview Wiring Instructions | Download Download Wiring Instructions

    IES Files

    Smart Blade IES Files |
    Download Download IES Files

    Warranty

    Standard Warranty |
    Preview Preview Warranty | Download Download Warranty
