Structure C5X

discontinued
indirect asymmetric/wall wash
white light

Asymmetric Wall Wash for Interior

Structure_C5X_07

Structure_C5X_09

Structure_C5X_10

Structure_C5X_06

Structure_C5X_02

Structure_C5X_01

Structure_C5X_03

Structure_C5X_05

Share this product page

White Light

C5X_2.0_ORTHO_Sus

Suspension

ORT_c5x_axa_x_cntd

Suspension Continuous

C5X_2.0_ORTHO_Pendant

Pendant

ORT_c5x_pna_cntd

Pendant Continuous

C5X_2.0_ORTHO_SurfaceMount

Surface

ORT_c5x_sma_cntd

Surface Continuous

C5X_2.0_ORTHO_ExtendedArm

Extended Arm

ORT_c5x_exa_cntd_c

Extended Arm Continuous

Structure C5X

Please see Structure C5X 2.0

Product Family: Discontinued

Share this product page

Light Source:

High Performance LED's
Output:

4.0 W/FT, 8.0 W/FT, 12.0 W/FT
Distribution:

Wall Wash, Indirect Asymmetric
White CCT:

2700K - 4000K
CRI:

82 CRI (Optional 90 CRI)
Performance:

Up to 8825 Delivered Lumens
Lumen Maintenance:

60,000 HRS L70
Voltage:

Universal 120-277V
Power:

Remote or Optional Integral Canopy
Dimming:

0-10V, Lutron
Lengths:

48", 72", 96", Continuous
Weight:

0.75 LBS/FT
Housing:

Precision Extruded Aluminum
End Caps:

Die-Cast or Brushed Machined Aluminum
Lens:

High Performance Extruded Acrylic
Finish:

High Durability Powder Coating
Warranty:

5-Year Limited
Certification:

ETL and cETL for Dry Location
